Cat.5e 180° Quick Solution - Keystone Jack
CAT 5e UTP 180° Quick Solution Keystone Jack is designed with easy installation in mind and compatible with CAT 5e component performance (ANSI/TIA-568-C.2 Category 5e). Compatible with SYSThames One Punch Tool which can reduce jack termination time and save time up to 8 times compared to traditional termination.
Key Features
- -Front Connection Spring Wire: Phosphor Bronze Alloy. Plated with 50 micro-inch of Gold over 70-100 micro-inch of Nickel
- -IDC: Phosphor Bronze Alloy with 10 micro-inch 100% Tin Alloy
- -Can terminate stranded or solid 22~26AWG wires.
- -T568A/B wiring
Product Overview
Applications
This product is ideal for use in:
- Voice; T1; ISDN
- 10BASE-T (IEEE 802.3)
- 16Mbps Token Ring (IEEE802.5)
- 100VG-AnyLAN (IEEE802.12)
- 100BASE-T Ethernet (IEEE802.3)
- 155/622Mbps 1.2/2.4 Gbps ATM
- 1000Mbps Gigabit Ethernet
- 550MHz Broadband Video
Quality Standards
All our products undergo rigorous quality testing to ensure reliable performance in real-world installations. This product complies with industry standards and is backed by our quality guarantee.
Technical Specifications
| Branding | Systhames Networking Ltd. |
|---|
Compliance
This product complies with the following standards:
- UL, ETL Verified
- ANSI/TIA-568-C.2
- ISO/IEC 11801
- EN 50173
